Bincolor BC-832 12V-24V 2CH PWM CV DMX512/1990 Decoder Led Controller

Be the first to review this product

SGD 44.77

In stock

SKU

Bincolor BC-832 12V-24V 2CH PWM CV DMX512/1990 Decoder

Bincolor BC-832 12V-24V 2CH PWM CV DMX512/1990 Decoder Led Controller is high quailty LED product for LED Lighting decoration, For big order or customized order, Pls feel free to contact service@agodeu.com

Agodeu.com brings advanced and effective LED products in Singapore, Indonesia, Malaysia, Philippines and worldwide. Quality LED Lighting Equipment And Systems With The Latest Technology. Quick shipping with tracking number, easy and safe ordering with PayPal and Credit Card.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Feature function:

Automatically adapt input voltage DC12V-24V.

Input standard DMX512 signal; 3-digital-display shows DMX address code..

2(BC-832)/3(BC-833)/4(BC-834) channels output; 4096 grey scales each; logarithmic dimming; lamplight soft& stable without strobe flash.

DMX Master mode, Slave mode available.

4 (BC-832)/8 (BC-833)/8 (BC-834)color changing modes and 10 speed scales in master mode .

Indicator of the DMX512 signal receiving status.

Wrong wiring protection at DMX input port.Over current protection and short circuit protection.

Power loss memory function.

BC-832

Product Model:BC-832

Input voltage:DC12V-DC24V

Max load current:8A/CH×2

Max Output Power:192W(12V)/384W(24V)

Grey Scale:4096 levels×2

Input Signal:DMX512/1990

Output Signal:Constant Voltage PWMX2

Decode Channel:2CH

DMX512 socket:Terminal Block

Dimension:L176×W46×H30(mm)

Weight (G.W):170g

Package Included:

1 Piece of Bincolor BC-832 12V-24V 2CH PWM CV DMX512/1990 Decoder Led Controller

Bincolor_Controller_BC_832_1

Bincolor_Controller_BC_832_2

Bincolor_Controller_BC_832_3

Bincolor_Controller_BC_832_4

Bincolor_Controller_BC_832_5

Bincolor_Controller_BC_832_6

Bincolor_Controller_BC_832_7

Bincolor_Controller_BC_832_8

CE and RoHS approved
